ABB ACS380 Series - Input References

108 Parameters
01.67 Abs output power %
drive nom
Absolute value of the output power % of drive nominal
01.16 Output power % of drive nom.
-
0.00… 300.00% 1= 1%
01.68 Abs motor shaft power Absolute value of the motor shaft power 01.17 Motor shaft
power.
-
0.00...30000.00 kW or
hp
1 = 1 kW
03
03 Input references
Values of references received from various sources.
All parameters in this group are read-only unless
otherwise noted.
03.01 Panel reference Local mode reference is given from the control panel. 0
-100000.00…
100000.00 rpm, Hz or
%
Control panel or PC tool reference. 1 = 10 unit
03.02 Panel reference
remote
Remote mode reference given from the control panel. -
-100000.00…
100000.00 rpm, Hz or
%
Control panel or PC tool reference. 1 = 10 unit
03.05 FB A reference 1 Scaled fieldbus A reference 1. See parameter 50.14 FBA
A reference 1.
0
-100000.00 …
100000.00
Reference from fieldbus adapter A. 1 = 10
03.06 FB A reference 2 Scaled fieldbus A reference 2. See parameter 50.15 FBA
A reference 2.
0
-100000.00 …
100000.00
Reference 2 from fieldbus adapter A. 1 = 10
03.09 EFB reference 1 Scaled reference 1 received through the embedded
fieldbus interface. The scaling is defined by 58.26 EFB
ref1 type
-
-30000.00 …
30000.00
Scaled reference 1 received through the embedded
fieldbus interface.
1 = 10
03.10 EFB reference 2 Scaled embedded fieldbus reference 2. -
-30000.00 …
30000.00
Scaled reference 2 received through the embedded
fieldbus interface. The scaling is defined by 58.27 EFB
ref2 type
1 = 10
03.17 Integrated panel
reference local
Local mode reference given from the integrated control
panel.Unit (rpm, Hz or %) is set from parameter
0
-100000.00 …
100000.00 rpm, Hz or
%
Integrated control panel reference. 1 = 10
03.18 Integrated panel
reference remote
Remote mode reference given from the integrated control
panel.
0
-100000.00 …
100000.00 rpm, Hz or
%
Integrated control panel reference. 1 = 10
No. Name/Value Description Default
FbEq 16
