316 Additional parameter data
03.05 FB A reference 1 Real -100000.00…100000.00 - 100 = 1
03.06 FB A reference 2 Real -100000.00…100000.00 - 100 = 1
03.09 EFB reference 1 Real -30000.00…30000.00 - 100 = 1
03.10 EFB reference 2 Real -30000.00…30000.00 - 100 = 1
03.17 Integrated panel reference
local
Real -100000.00…100000.00 - 100 = 1
03.18 Integrated panel reference
remote
Real -100000.00…100000.00 - 100 = 1
04 Warnings and faults
04.01 Tripping fault Data 0000h…FFFFh - 1 = 1
04.02 Active fault 2 Data 0000h…FFFFh - 1 = 1
04.03 Active fault 3 Data 0000h…FFFFh - 1 = 1
04.06 Active warning 1 Data 0000h…FFFFh - 1 = 1
04.07 Active warning 2 Data 0000h…FFFFh - 1 = 1
04.08 Active warning 3 Data 0000h…FFFFh - 1 = 1
04.11 Latest fault Data 0000h…FFFFh - 1 = 1
04.12 2nd latest fault Data 0000h…FFFFh - 1 = 1
04.13 3rd latest fault Data 0000h…FFFFh - 1 = 1
04.16 Latest warning Data 0000h…FFFFh - 1 = 1
04.17 2nd latest warning Data 0000h…FFFFh - 1 = 1
04.18 3rd latest warning Data 0000h…FFFFh - 1 = 1
05 Diagnostics
05.01 On-time counter Real 0…65535 d 1 = 1 d
05.02 Run-time counter Real 0…65535 d 1 = 1 d
05.04 Fan on-time counter Real 0…65535 d 1 = 1 d
05.10 Control board temperature Real -100…300 °C °C or °F 10 = 1 °C
05.11 Inverter temperature Real -40.0…160.0 % 10 = 1%
05.22 Diagnostic word 3 PB 0000h…FFFFh -
06 Control and status words
06.01 Main control word PB 0000h…FFFFh - 1 = 1
06.11 Main status word PB 0000h…FFFFh - 1 = 1
06.16 Drive status word 1 PB 0000h…FFFFh - 1 = 1
06.17 Drive status word 2 PB 0000h…FFFFh - 1 = 1
06.18 Start inhibit status word PB 0000h…FFFFh - 1 = 1
06.19 Speed control status word PB 0000h…FFFFh - 1 = 1
06.20 Constant speed status word PB 0000h…FFFFh - 1 = 1
06.21 Drive status word 3 PB 0000h…FFFFh - 1 = 1
06.30 MSW bit 11 selection Binary
src
--1 = 1
06.31 MSW bit 12 selection Binary
src
--1 = 1
No. Name Type Range Unit FbEq32
