274 Parameters
Transparent 32 Transparent control profile (with a 32-bit control word). 9
58.26 EFB ref1 type Selects the type and scaling of reference 1 received
through the embedded fieldbus interface.
The scaled reference is displayed by 03.09 EFB reference
1.
Speed or
frequency
Speed or frequency Type and scaling is chosen automatically according to the
currently active operation mode as follows.
0
Transparent No scaling is applied. 1
General Generic reference without a specific unit. Scaling: 1 = 100. 2
Torque Torque reference. The scaling is defined by parameter
46.03 Torque scaling.
3
Speed Speed reference. The scaling is defined by parameter
46.01 Speed scaling.
4
Frequency Frequency reference. The scaling is defined by parameter
46.02 Frequency scaling.
5
58.27 EFB ref2 type Selects the type and scaling of reference 2 received
through the embedded fieldbus interface.
The scaled reference is displayed by 03.10 EFB reference
2.
Torque
58.28 EFB act1 type Selects the type/source and scaling of actual value 1
transmitted to the fieldbus.network through the embedded
fieldbus interface.
Speed or
frequency
Speed or frequency Type and scaling is chosen automatically according to the
currently active operation mode as follows:
0
Transparent The value selected by parameter 58.31 EFB act1
transparent source is sent as actual value 1. No scaling is
applied (the 16-bit scaling is 1 = 1 unit).
1
General The value selected by parameter 58.31 EFB act1
transparent source is sent as actual value 1 with a 16-bit
scaling of 100 =1 unit (ie. integer and two decimals).
2
Torque 01.10 Motor torque is sent as actual value 1. Scaling is
defined by parameter 46.03 Torque scaling.
3
Speed 01.01 Motor speed used is sent as actual value 1. Scaling
is defined by parameter 46.01 Speed scaling.
4
No. Name/Value Description Default
FbEq 16
Operation mode
(see par. 19.01)
Reference 1 type
Speed control Speed
Torque control Speed
Frequency control Frequency
Operation mode
(see par. 19.01)
Actual 1 type (source) Scaling
Speed control
Speed
(01.01 Motor speed used)
46.01 Speed scaling
Torque control
Frequency control
Frequency
(01.06 Output frequency)
46.02 Frequency scaling
