Parameters 275
Frequency 01.06 Output frequency is sent as actual value 1. Scaling
is defined by parameter 46.02 Frequency scaling.
5
58.29 EFB act2 type Selects the type/source and scaling of actual value 2
transmitted to the fieldbus network through the embedded
fieldbus interface.
Torque
Speed or frequency Type/source and scaling are chosen automatically
according to the currently active operation mode as
follows:
Transparent The value selected by parameter 58.32 EFB act2
transparent source is sent as actual value 2. No scaling is
applied (the 16-bit scaling is 1 = 1 unit).
1
General The value selected by parameter 58.32 EFB act2
transparent source is sent as actual value 2 with a 16-bit
scaling of 100 =1 unit (i.e. integer and two decimals).
2
Torque 01.10 Motor torque is sent as actual value 2. Scaling is
defined by parameter 46.03 Torque scalingg.
3
Speed 01.01 Motor speed used is sent as actual value 2. Scaling
is defined by parameter 46.01 Speed scaling.
4
Frequency 01.06 Output frequency is sent as actual value 2. Scaling
is defined by parameter 46.02 Frequency scaling.
5
58.31 EFB act1 transparent
source
Selects the source of actual value 1 when parameter
58.28 EFB act1 type is set to Transparent.
Not selected
Not selected None. 0
Other Source selection (see Terms and abbreviations). -
58.32 EFB act2 transparent
source
Selects the source of actual value 1 when parameter
58.29 EFB act2 type is set to Transparent.
Other (par.
01.07 Motor
current
)
Not selected None. 0
Other Source selection (see Terms and abbreviations). -
No. Name/Value Description Default
FbEq 16
Operation mode
(see par. 19.01)
Actual 1 type (source) Scaling
Speed control
Speed
(01.01 Motor speed used)
46.01 Speed scaling
Torque control
Frequency control
Frequency
(01.06 Output frequency)
46.02 Frequency scaling
