106 Parameters
01.10 Motor torque Motor torque in percent of the nominal motor torque. See
also parameter 01.30 Nominal torque scale.
A filter time constant for this signal can be defined by
parameter 46.13 Filter time motor torque.
-
-1600.0…1600.0% Motor torque. See par.
46.03
01.11 DC voltage Measured intermediate circuit DC Link voltage. -
0.00…2000.00 V DC link voltage. 10 = 1 V
01.13 Output voltage Calculated motor voltage in V AC. -
0…2000 V Motor voltage. 1 = 1 V
01.14 Output power Measured output power in kW or hp, depending on setting
of parameter Power unit. The filter time constant can be
adjusted by parameter 46.14 Filter time power.
-
-32768.00… 32767.00
kW or hp
Output power. 1 = 1 unit
01.15 Output power % of
motor nom
Measured output power in % of nominal motor power. -
-300.00… 300.00% Output power. 1 = 1%
01.16 Output power % of
drive nom
Measured output power in % of drive nominal power. The
filter time constant can be adjusted by parameter 46.14
Filter time power.
-
-300.00… 300.00% Output power. 1 = 1%
01.17 Motor shaft power Estimated mechanical power at motor shaft in kW or hp.
The unit is selected by parameter 96.16 Unit selection.The
filter time constant can be adjusted by parameter 46.14
Filter time power.
-
-32768.00… 32767.00
kW or hp
Motor shaft power. 1 = 1 unit
01.18 Inverter GWh counter Amount of energy that has passed through the drive (in
either direction) in full gigawatt-hours. The minimum value
is zero.
-
0…65535 GWh Energy in GWh. 1 = 1 GWh
01.19 Inverter MWh counter Amount of energy that has passed through the drive (in
either direction) in full megawatt-hours. Whenever the
counter rolls over, 01.18 Inverter GWh counter is
incremented. The minimum value is zero.
-
0…1000 MWh Energy in MWh. 1 = 1 MWh
01.20 Inverter kWh counter Amount of energy that has passed through the drive (in
either direction) in full kilowatt-hours. Whenever the
counter rolls over, 01.19 Inverter MWh counter is
incremented. The minimum value is zero.
-
0…1000 kWh Energy in kWh. 10 = 1 kWh
01.24 Flux actual % Used flux reference in percent of nominal flux of motor. -
0…200% Flux reference. 1 = 1%
No. Name/Value Description Default
FbEq 16
