Additional parameter data 319
11.47 Freq in 2 scaled value Real -32768.000…32767.000 - 1000 = 1
11.50 Freq in 2 min Real 0…16000 Hz 1 = 1
11.51 Freq in 2 max Real 0…16000 Hz 1 = 1
11.52 Freq in 2 at scaled min Real -32768.000…32767.000 - 1 = 1
11.53 Freq in 2 at scaled max Real -32768.000…32767.000 - 1 = 1
11.54 Freq out 1 actual value Real 0…16000 Hz 1 = 1
11.55 Freq out 1 source List --1 = 1
11.58 Freq out 1 src min Real -32768.000…32767.000 - 1 = 1
11.59 Freq out 1 src max Real -32768.000…32767.000 - 1 = 1
11.60 Freq out 1 at src min Real 0…16000 Hz 1 = 1
11.61 Freq out 1 at src max Real 0…16000 Hz 1 = 1
11.62 Freq out 2 actual value Real 0…16000 Hz 1 = 1
11.63 Freq out 2 source List --1 = 1
11.66 Freq out 2 source min Real -32768.000…32767.000 - 1 = 1
11.67 Freq out 2 source max Real -32768.000…32767.000 - 1 = 1
11.68 Freq out 2 at src min Real 0…16000 Hz 1 = 1
11.69 Freq out 2 at src max Real 0…16000 Hz 1 = 1
12 Standard AI
12.02 AI force selection PB 0000h…FFFFh - 1 = 1
12.03 AI supervision function List 0…4 - 1 = 1
12.04 AI supervision selection PB 0000h…FFFFh - 1 = 1
12.11 AI1 actual value Real 4.000…20.000 mA or
0.000…10.000 V
mA or V 1000 = 1 unit
12.12 AI1 scaled value Real -32768.000…32767.000 - 1000 = 1
12.13 AI1 forced value Real 4.000…20.000 mA or
0.000…10.000 V
mA or V 1000 = 1 unit
12.15 AI1 unit selection List 2, 10 - 1 = 1
12.16 AI1 filter time Real 0.000…30.000 s 1000 = 1 s
12.17 AI1 min Real 4.000…20.000 mA or
0.000…10.000 V
mA or V 1000 = 1 unit
12.18 AI1 max Real 0.000…20.000 mA or
0.000…10.000 V
mA or V 1000 = 1 unit
12.19 AI1 scaled at AI1 min Real -32768.000…32767.000 - 1000 = 1
12.20 AI1 scaled at AI1 max Real -32768.000…32767.000 - 1000 = 1
12.21 AI2 actual value Real 4.000…20.000 mA or
0.000…10.000 V
mA or V 1000 = 1 unit
12.22 AI2 scaled value Real -32768.000…32767.000 - 1000 = 1
12.23 AI2 forced value Real 4.000…20.000 mA or
0.000…10.000 V
mA or V 1000 = 1 unit
12.25 AI2 unit selection List 2, 10 - 1 = 1
12.26 AI2 filter time Real 0.000…30.000 s 1000 = 1 s
12.27 AI2 min Real 4.000…20.000 mA or
0.000…10.000 V
mA or V 1000 = 1 unit
No. Name Type Range Unit FbEq32
