132 Parameters
Process PID out 40.01 Process PID output actual 16
Temp sensor 1
excitation
The output is used to feed an excitation current to the
temperature sensor 1, see parameter 35.11 Temperature
1 source. See also section Motor thermal protection.
20
Temp sensor 2
excitation
The output is used to feed an excitation current to the
temperature sensor 2, see parameter 35.21 Temperature
2 source. See section Motor thermal protection in chapter
Program features.
21
Abs motor speed used 01.61 Abs motor speed used 26
Abs motor speed % 01.62 Abs motor speed % 27
Abs output frequency 01.63 Abs output frequency 28
Abs motor torque 01.64 Abs motor torque 30
Abs output power 01.65 Abs output power 31
Abs motor shaft power 01.68 Abs motor shaft power 32
External PID1 out 71.01 External PID act value 33
AO1 data storage 13.91 AO1 data storage 37
Other Source selection (see Terms and abbreviations). -
13.13 AO1 forced value Forced value that can be used instead of the selected
output signal. See parameter 13.02 AO force selection.
0.000 mA
- 1000 = 1 -
13.15 AO1 unit selection Selects the unit for readings and settings related to analog
input AO1.
Note: This setting must match the corresponding
hardware setting on the drive control unit (see the drive
hardware manual). See the default control connections for
the macro in use in chapter Control macros. Control board
reboot (either by cycling the power or through parameter
96.08 Control board boot) is required to validate any
changes in the hardware settings.
mA
VVolts. 0
mA Milliamperes. 1
No. Name/Value Description Default
FbEq 16
