Parameters 147
20.07 Ext2 start trigger type Defines whether the start signal for external control
location EXT2 is edge-triggered or level-triggered.
Note: This parameter is not effective if a pulse-type start
signal is selected. See the descriptions of the selections of
parameter 20.06 Ext2 commands.
Level
Edge The start signal is edge-triggered. 0
Level The start signal is level-triggered. 1
20.08 Ext2 in1 Selects source 1 for parameter 20.06 Ext2 commands.
For the available selections, see parameter 20.03 Ext1
in1.
Not selected
20.09 Ext2 in2 Selects source 2 for parameter 20.06 Ext2 commands.
For the available selections, see parameter 20.03 Ext1
in1.
Not selected
20.10 Ext2 in3 Selects source 3 for parameter 20.06 Ext2 commands.
For the available selections, see parameter 20.03 Ext1
in1.
Not selected
20.11 Run enable stop mode Selects the way the motor is stopped when the run enable
signal switches off.
The source of the run enable signal is selected by
parameter 20.12 Run enable 1.
Coast
Coast Stop by switching off the output semiconductors of the
drive. The motor coasts to a stop.
WARNING! If a mechanical brake is used, ensure
it is safe to stop the drive by coasting.
0
Ramp Stop along the active deceleration ramp. See parameter
group 23 Speed reference ramp.
1
Torque limit Stop according to torque limits (parameters 30.19 and
30.20).
2
20.12 Run enable 1 Selects the source of the external run enable signal. If the
run enable signal is switched off, the drive will not start. If
already running, the drive will stop according to the setting
of parameter 20.11 Run enable stop mode.
1 = Run enable signal on.
Note: This parameter cannot be changed while the drive
is running.
See also parameter 20.19 Enable start signal
Selected
Not selected 0. 0
Selected 1. 1
DI1 Digital input DI1 (10.02 DI delayed status, bit 0). 2
DI2 Digital input DI2 (10.02
DI delayed status, bit 1). 3
DI3 Digital input DI3 (10.02 DI delayed status, bit 2). 4
DI4 Digital input DI4 (10.02 DI delayed status, bit 3). 5
DIO1 Digital input/output DIO1 (11.02 DIO delayed status, bit 0) 10
DIO2 Digital input/output DIO2 (11.02 DIO delayed status, bit 0) 11
Timed function 1 Bit 0 of 34.01 Timed functions status.18
Timed function 2 Bit 1 of 34.01 Timed functions status.19
Timed function 3 Bit 2 of 34.01 Timed functions status.20
Supervision 1 Bit 0 of 32.01 Supervision status.24
No. Name/Value Description Default
FbEq 16
