22.21 Constant speed
function
Determines how constant speeds are selected, and
whether the rotation direction signal is considered or not
when applying a constant speed.
01b
00b…11b Constant speed configuration word. 1 = 1
22.22 Constant speed sel1 When bit 0 of parameter 22.21 Constant speed function is
0 (Separate), selects a source that activates constant
speed 1.
When bit 0 of parameter 22.21 Constant speed function is
1 (Packed), this parameter and parameters 22.23
Constant speed sel2 and 22.24 Constant speed sel3
select three sources whose states activate constant
speeds as follows:
DI2
Not selected 0 (always off). 0
Selected 1 (always on). 1
DI1 Digital input DI1 (10.02 DI delayed status, bit 0). 2
DI2 Digital input DI2 (10.02 DI delayed status, bit 1). 3
DI3 Digital input DI3 (10.02 DI delayed status, bit 2). 4
DI4 Digital input DI4 (10.02 DI delayed status, bit 3). 5
DIO1 Digital input/output DIO1 (11.02 DIO delayed status, bit 0) 10
DIO2 Digital input/output DIO2 (11.02 DIO delayed status, bit 0) 11
Timed function 1 Bit 0 of 34.01 Timed functions status.18
Timed function 2 Bit 1 of 34.01 Timed functions status.19
Timed function 3 Bit 2 of 34.01 Timed functions status.20
Supervision 1 Bit 0 of 32.01 Supervision status.24
No. Name/Value Description Default
FbEq 16
Bit Name Information
0 Constant speed
mode
1 = Packed: 7 constant speeds are selectable using the three sources
defined by parameters 22.22, 22.23 and 22.24.
0 = Separate: Constant speeds 1, 2 and 3 are separately activated by
the sources defined by parameters 22.22, 22.23 and 22.24 respectively.
In case of conflict, the constant speed with the smaller number takes
priority.
1 Direction
enable
2…15 Reserved
Source defined
by par. 22.22
Source defined
by par. 22.23
Source defined
by par. 22.24
Constant speed active
0 0 0 None
1 0 0 Constant speed 1
0 1 0 Constant speed 2
1 1 0 Constant speed 3
0 0 1 Constant speed 4
1 0 1 Constant speed 5
0 1 1 Constant speed 6
1 1 1 Constant speed 7
