ABB ACS380 Series - Page 167

Parameters 167
Supervision 2 Bit 1 of 32.01 Supervision status.25
Supervision 3 Bit 2 of 32.01 Supervision status.26
Supervision 4 Bit 3 of 32.01 Supervision status.27
Supervision 5 Bit 4 of 32.01 Supervision status.28
Supervision 6 Bit 5 of 32.01 Supervision status.29
Other [bit] Source selection (see Terms and abbreviations). -
22.23 Constant speed sel2 When bit 0 of parameter 22.21 Constant speed function is
0 (Separate), selects a source that activates constant
speed 2.
When bit 0 of parameter 22.21 Constant speed function is
1 (Packed), this parameter and parameters 22.22
Constant speed sel1 and 22.24 Constant speed sel3
select three sources that are used to activate constant
speeds.
For the selections, see parameter 22.22 Constant speed
sel1.
DI4
22.24 Constant speed sel3 When bit 0 of parameter 22.21 Constant speed function is
0 (Separate), selects a source that activates constant
speed 3.
When bit 0 of parameter 22.21 Constant speed function is
1 (Packed), this parameter and parameters 22.22
Constant speed sel1 and 22.23 Constant speed sel2
select three sources that are used to activate constant
speeds. See table at parameter 22.22 Constant speed
sel1.
For the selections, see parameter 22.22 Constant speed
sel1.
Not selected
22.26 Constant speed 1 Defines constant speed 1 (the speed the motor will turn
when constant speed 1 is selected).
300.00 rpm
-30000.00… 30000.00
rpm
Constant speed 1. See par.
46.01
22.27 Constant speed 2 Defines constant speed 2. 600.00 rpm
-30000.00… 30000.00
rpm
Constant speed 2. See par.
46.01
22.28 Constant speed 3 Defines constant speed 3. 900.00 rpm
-30000.00… 30000.00
rpm
Constant speed 3. See par.
46.01
22.29 Constant speed 4 Defines constant speed 4. 1200.00 rpm
-30000.00… 30000.00
rpm
Constant speed 4. See par.
46.01
22.30 Constant speed 5 Defines constant speed 5. 1500.00 rpm
-30000.00… 30000.00
rpm
Constant speed 5. See par.
46.01
22.31 Constant speed 6 Defines constant speed 6. 2400.00 rpm
-30000.00… 30000.00
rpm
Constant speed 6. See par.
46.01
22.32 Constant speed 7 Defines constant speed 7. 3000.00 rpm
-30000.00… 30000.00
rpm
Constant speed 7. See par.
46.01
No. Name/Value Description Default
FbEq 16
