48 Control macros
96.04 Macro select 1 =
ABB standard
12 =
Alternate
1 3 =
Motor potenti-
ometer
14 =
PID
22.71 Motor
potentiometer
function
0 = Disabled 0 = Disabled 1 = Enabled
(init at power-
up)
0 = Disabled
22.73 Motor
potentiometer up
source
0 = Not
selected
0 = Not
selected
4 = DI3 0 = Not
selected
22.74 Motor
potentiometer
down source
0 = Not
selected
0 = Not
selected
5 = DI4 0 = Not
selected
23.11 Ramp set
selection
10 = DIO1 10 = DIO1 0 = Acc/Dec
time 1
0 = Acc/Dec
time 1
28.11 Ext1 frequency
ref1
1 = AI1 scaled 1 = AI1 scaled 15 = Motor
potentiometer
16 = PID
28.15 Ext1 frequency
ref2
0 = Zero 0 = Zero 0 = Zero 0 = Zero
28.22 Constant
frequency sel1
4 = DI3 4 = DI3 10 = DIO1 5 = DI4
28.23 Constant
frequency sel2
5 = DI4 5 = DI4 0 = Not
selected
0 = Not
selected
28.71 Freq ramp set
selection
10 = DIO1 10 =
DIO1 0 = Acc/Dec
time 1
0 = Acc/Dec
time 1
40.07 Process PID
operation mode
0 = Off 0 = Off 0 = Off 2 = On when
drive running
40.16 Set 1 setpoint 1
source
11 = AI1
percent
11 = AI1
percent
11 = AI1
percent
11 = AI1
percent
40.17 Set 1 setpoint 2
source
0 = Not
selected
0 = Not
selected
0 = Not
selected
2 = Internal
setpoint
40.19 Set 1 internal
setpoint sel1
0 = Not
selected
0 = Not
selected
0 = Not
selected
3 = DI2
40.20 Set 1 internal
setpoint sel2
0 = Not
selected
0 = Not
selected
0 = Not
selected
4 = DI3
40.32 Set 1 gain 1.00 1.00 1.00 1.00
40.33 Set 1 integration
time
60.0 60.0 60.0 60.0
