170 Parameters
Supervision 2 Bit 1 of 32.01 Supervision status.25
Supervision 3 Bit 2 of 32.01 Supervision status.26
Supervision 4 Bit 3 of 32.01 Supervision status.27
Supervision 5 Bit 4 of 32.01 Supervision status.28
Supervision 6 Bit 5 of 32.01 Supervision status.29
Other [bit] Source selection (see Terms and abbreviations). -
22.74 Motor potentiometer
down source
Selects the source of motor potentiometer down signal.
0 = No change
1 = Decrease motor potentiometer value. (If both the up
and down sources are on, the potentiometer value will not
change.)
For the selections, see parameter 22.73.
Not selected
22.75 Motor potentiometer
ramp time
Defines the change rate of the motor potentiometer. This
parameter specifies the time required for the motor
potentiometer to change from minimum (parameter 22.76)
to maximum (parameter 22.77). The same change rate
applies in both directions.
40.0 s
0.0…3600.0 s Motor potentiometer change time. 1 = 1 s
22.76 Motor potentiometer
min value
Defines the minimum value of the motor potentiometer.
Note: If vector control mode is used, the value of this
parameter must be changed.
0.00
-32768.00… 32767.00 Motor potentiometer minimum. 1 = 1
22.77 Motor potentiometer
max value
Defines the maximum value of the motor potentiometer.
Note: If vector control mode is used, the value of this
parameter must be changed.
50.00
-32768.00… 32767.00 Motor potentiometer maximum. 1 = 1
22.80 Motor potentiometer
ref act
Shows the output of the motor potentiometer function.
(The motor potentiometer is configured using parameters
22.71…22.74.)
This parameter is read-only.
-
-32768.00… 32767.00 Value of motor potentiometer. 1 = 1
22.86 Speed reference act 6 Displays the value of the speed reference (Ext1 or Ext2)
that has been selected by 19.11 Ext1/Ext2 selection. See
diagram at 22.11 Ext1 speed ref1 or the control chain
diagram on page 448.
This parameter is read-only.
-
-30000.00… 30000.00
rpm
Speed reference after additive 2. See par.
46.01
