Parameters 189
28.22 Constant frequency
sel1
When bit 0 of parameter 28.21 Constant frequency
function is 0 (Separate), selects a source that activates
constant frequency 1.
When bit 0 of parameter 28.21 Constant frequency
function is 1 (Packed), this parameter and parameters
28.23 Constant frequency sel2 and 28.24 Constant
frequency sel3 select three sources whose states activate
constant frequencies as follows:
Not selected
Not selected 0. 0
Selected 1. 1
DI1 Digital input DI1 (10.02 DI delayed status, bit 0). 2
DI2 Digital input DI2 (10.02 DI delayed status, bit 1). 3
DI3 Digital input DI3 (10.02 DI delayed status, bit 2). 4
DI4 Digital input DI4 (10.02 DI delayed status, bit 3). 5
DIO1 Digital input/output DIO1 (11.02 DIO delayed status, bit 0) 10
DIO2 Digital input/output DIO2 (11.02 DIO delayed status, bit 0) 11
Timed function 1 Bit 0 of 34.01 Timed functions status.18
Timed function 2 Bit 1 of 34.01 Timed functions status.19
Timed function 3 Bit 2 of 34.01 Timed functions status.20
Supervision 1 Bit 0 of 32.01 Supervision status.24
Supervision 2 Bit 1 of 32.01 Supervision status.25
Supervision 3 Bit 2 of 32.01 Supervision status.26
Supervision 4 Bit 3 of 32.01 Supervision status.27
Supervision 5 Bit 4 of 32.01 Supervision status.28
Supervision 6 Bit 5 of 32.01 Supervision status.29
Other [bit] Source selection (see Terms and abbreviations). -
No. Name/Value Description Default
FbEq 16
Source defined
by par. 28.22
Source defined
by par. 28.23
Source defined
by par. 28.24
Constant frequency
active
000 None
1 0 0 Constant frequency 1
0 1 0 Constant frequency 2
1 1 0 Constant frequency 3
0 0 1 Constant frequency 4
1 0 1 Constant frequency 5
0 1 1 Constant frequency 6
1 1 1 Constant frequency 7
