Parameters 143
In1P Start; In2 Stop;
In3 Dir
The sources of the start and stop commands are selected
by parameters 20.03 Ext1 in1 and 20.04 Ext1 in2. The
source selected by 20.05 Ext1 in3 determines the
direction. The state transitions of the source bits are
interpreted as follows:
Notes:
• Parameter 20.02 Ext1 start trigger type has no effect
with this setting.
• When source 2 is 0, the Start and Stop keys on the
control panel are disabled.
5
In1P Start fwd; In2P
Start rev; In3 Stop
The sources of the start and stop commands are selected
by parameters 20.03 Ext1 in1, 20.04 Ext1 in2 and 20.05
Ext1 in3. The source selected by 20.05 Ext1 in3
determines the direction. The state transitions of the
source bits are interpreted as follows:
Note: Parameter 20.02 Ext1 start trigger type has no
effect with this setting.
6
Control panel Start; stop and direction commands through control panel;
when EXT1 is active. Applies also for PC-Tool when it is
connected via panel port.
11
Fieldbus A The start and stop commands are taken from fieldbus
adapter A.
Note: Set also 20.02 Ext1 start trigger type to Level.
12
Embedded fieldbus The start and stop commands are taken from the
embedded fieldbus interface.
Note: Set also 20.02 Ext1 start trigger type to Level.
14
M/F link Start; stop and direction commands through D2D link
when EXT1 is active.
15
ABB Controller Start, stop and direction commands through DDCS from
ABB controller.
16
ATF Start, stop and direction commands from ATF when EXT1
is active.
22
Integrated Panel Start; stop and direction commands from Integrated Panel 23
No. Name/Value Description Default
FbEq 16
State of
source 1
(20.03)
State of
source 2
(20.04)
State of
source 3
(20.05)
Command
0
-
> 1 1 0 Start forward
0
-
> 1 1 1 Start reverse
Any 0 Any Stop
State of
source 1
(20.03)
State of
source 2
(20.04)
State of
source 3
(20.05)
Command
0
-
> 1 Any 1 Start forward
Any 0
-
> 1 1 Start reverse
Any Any 0 Stop
