In1 Start The source of the start and stop commands is selected by
parameter 20.08 Ext2 in1. The state transitions of the
source bits are interpreted as follows:
1
In1 Start; In2 Dir The source selected by 20.08 Ext2 in1 is the start signal;
the source selected by 20.09 Ext2 in2 determines the
direction. The state transitions of the source bits are
interpreted as follows:
2
In1 Start fwd; In2 Start
rev
The source selected by 20.08 Ext2 in1 is the forward start
signal; the source selected by 20.09 Ext1 in2 is the
reverse start signal. The state transitions of the source bits
are interpreted as follows:
3
In1P Start; In2 Stop The sources of the start and stop commands are selected
by parameters 20.08 Ext2 in1 and 20.09 Ext1 in2. The
state transitions of the source bits are interpreted as
follows:
Notes:
• Parameter 20.07 Ext2 start trigger type has no effect
with this setting.
• When source 2 is 0, the Start and Stop keys on the
control panel are disabled.
4
No. Name/Value Description Default
FbEq 16
State of source 1 (20.08) Command
0 -> 1 (20.07 = Edge)
1 (20.07 = Level)
Start
0Stop
State of source 1
(20.08)
State of source 2
(20.09)
Command
0 Any Stop
0 -> 1 (20.07 = Edge)
1 (20.07 = Level)
0 Start forward
1 Start reverse
State of source 1
(20.08)
State of source 2
(20.09)
Command
00Stop
0 -> 1 (20.07 = Edge)
1 (20.07 = Level)
0 Start forward
0
0 -> 1 (20.07 = Edge)
1 (20.07 = Level)
Start reverse
11Stop
State of source 1
(20.08)
State of source 2
(20.09)
Command
0
-
> 1 1 Start
Any 0 Stop
