Parameters 227
All Reset both the peak value logger and amplitude logger 2. 1
PVL Reset the peak value logger. 2
AL2 Reset amplitude logger 2. 3
36.10 PVL peak value Shows the peak value recorded by the peak value logger. 0.00
-32768.00… 32767.00 Peak value. 1 = 1
36.11 PVL peak date Shows the date when the peak value was recorded. 01.01.1980
- Peak occurrence date. -
36.12 PVL peak time Shows the time when the peak value was recorded. 00:00:00
- Peak occurrence time. -
36.13 PVL current at peak Shows the Motor current at the moment the peak value
was recorded.
0.00 A
-32768.00… 32767.00
A
Motor current at peak. 1 = 1 A
36.14 PVL DC voltage at
peak
Shows the voltage in the intermediate DC circuit of the
drive at the moment the peak value was recorded.
0.00 V
0.00…2000.00 V DC voltage at peak. 10 = 1 V
36.15 PVL speed at peak Shows the Motor speed at the moment the peak value
was recorded.
0.00 rpm
-30000… 30000 rpm Motor speed at peak. See par.
46.01
36.16 PVL reset date Shows the date on which the peak value logger was last
reset.
01.01.1980
- Last reset date of the peak value logger. -
36.17 PVL reset time Shows the time when the peak value logger was last
reset.
00:00:00
- Last reset time of the peak value logger. -
36.20 AL1 0 to 10% Shows the percentage of samples recorded by amplitude
logger 1 that fall between 0 and 10%. 100% corresponds
to the I
max
value given in the ratings table in chapter
Technical data in the hardware manual.
0.00%
0.00…100.00% Amplitude logger 1 samples between 0 and 10%. 1 = 1%
36.21 AL1 10 to 20% Shows the percentage of samples recorded by amplitude
logger 1 that fall between 10 and 20%.
0.00%
0.00…100.00% Amplitude logger 1 samples between 10 and 20%. 1 = 1%
36.22 AL1 20 to 30% Shows the percentage of samples recorded by amplitude
logger 1 that fall between 20 and 30%.
0.00%
0.00…100.00% Amplitude logger 1 samples between 20 and 30%. 1 = 1%
36.23 AL1 30 to 40% Shows the percentage of samples recorded by amplitude
logger 1 that fall between 30 and 40%.
0.00%
0.00…100.00% Amplitude logger 1 samples between 30 and 40%. 1 = 1%
36.24 AL2 40 to 50% Shows the percentage of samples recorded by amplitude
logger 1 that fall between 40 and 50%.
0.00%
0.00…100.00% Amplitude logger 1 samples between 40 and 50%. 1 = 1%
No. Name/Value Description Default
FbEq 16
