Additional parameter data 343
98.04 Lm user Real 0.00000…10.00000 p.u. 100000 = 1
p.u.
98.05 SigmaL user Real 0.00000…1.00000 p.u. 100000 = 1
p.u.
98.06 Ld user Real 0.00000…10.00000 p.u. 100000 = 1
p.u.
98.07 Lq user Real 0.00000…10.00000 p.u. 100000 = 1
p.u.
98.08 PM flux user Real 0.00000…2.00000 p.u. 100000 = 1
p.u.
98.09 Rs user SI Real 0.00000…100.00000 ohm 100000 = 1
p.u.
98.10 Rr user SI Real 0.00000…100.00000 ohm 100000 = 1
p.u.
98.11 Lm user SI Real 0.00…100000.00 mH 100 = 1 mH
98.12 SigmaL user SI Real 0.00…100000.00 mH 100 = 1 mH
98.13 Ld user SI Real 0.00…100000.00 mH 100 = 1 mH
98.14 Lq user SI Real 0.00…100000.00 mH 100 = 1 mH
99 Motor data
99.03 Motor type List 0…1 - 1 = 1
99.04 Motor control mode List 0…1 - 1 = 1
99.06 Motor nominal current Real 0.0…6400.0 A 10 = 1 A
99.07 Motor nominal voltage Real 0.0…800.0 V 10 = 1 V
99.08 Motor nominal frequency Real 0.0 … 500.0 Hz 10 = 1 Hz
99.09 Motor nominal speed Real 0 … 30000 rpm 1 = 1 rpm
99.10 Motor nominal power Real -10000.00…10000.00 kW
or
-13405.83 … 13405.83 hp
kW or hp 100 = 1 unit
99.11 Motor nominal cos Φ Real 0.00 … 1.00 - 100 = 1
99.12 Motor nominal torque Real 0.000… N·m or
lb·ft
1000 = 1 unit
99.13 ID run requested List 0…3, 5…6, - 1 = 1
99.14 Last ID run performed List 0…3, 5…6, - 1 = 1
99.15 Motor polepairs calculated Real 0…1000 - 1 = 1
99.16 Motor phase order List 0…1 - 1 = 1
No. Name Type Range Unit FbEq32
