Fieldbus control through the embedded fieldbus interface (EFB) 411
Status Word for the Transparent 16 Profile
Status word of the Transparent 16 profile can be read from the object 2054h.
13 RAMP_IN_ZERO 1 Force Ramp Function Generator input to zero.
0 Normal operation.
14 REQ_LOCAL_LO
CK
1 Not yet implemented.
0 Not yet implemented.
15 Reserved for
TORQ_LIM_PAIR
_2
Not yet implemented.
Bit Name Value State/Description
0 READY 1 Drive is ready to receive the start command.
0 Drive is not ready.
1 ENABLED 1 External run enable signal is active.
0 External run enable signal is not active.
2 Reserved for
ENABLED_TO_R
OTATE
Not yet implemented.
3 RUNNING 1 Drive is modulating.
0 Drive is not modulating.
4 ZERO_SPEED 1 Drive is at zero speed.
0 Drive is not at zero speed.
5 ACCELERATING 1 Not yet implemented.
0 Not yet implemented.
6 DECELERATING 1 Not yet implemented.
0 Not yet implemented.
7 AT_SETPOINT 1 Drive is at setpoint.
0 Drive is not at setpoint.
8 LIMIT 1 Drive operation is limited.
0 Drive operation is not limited.
9 SUPERVISION 1 Actual value (speed, frequency or torque) is above a
limit. Limit is set with parameters 46.31…46.33
0 Actual value (speed, frequency or torque) is within
limits.
10 REVERSE_REF 1 Not yet implemented.
0 Not yet implemented.
11 REVERSE_ACT 1 Not yet implemented.
0 Not yet implemented.
Bit Name Value State/Description
