Fieldbus control through the embedded fieldbus interface (EFB) 413
6 RUN_DISABLE 1 Run disable. If the drive is set to receive the run enable
signal from the fieldbus, this bit deactivates the signal.
0 Run enable. If the drive is set to receive the run enable
signal from the fieldbus, this bit activates the signal.
7 STOPMODE_RA
MP
1 Normal ramp stop mode
0 (no op) Default to parameter stop mode if bits 7…9 are all
0.
8 STOPMODE_EM
ERGENCY_RAM
P
1 Emergency ramp stop mode.
0 (no op) Default to parameter stop mode if bits 7…9 are all
0.
9 STOPMODE_CO
AST
1 Coast stop mode.
0 (no op) Default to parameter stop mode if bits 7…9 are all
0.
10 Reserved for
RAMP_PAIR _2
Not yet implemented.
11 RAMP_OUT_ZER
O
1 Force Ramp Function Generator output to zero. Drive
ramps to stop (current and DC voltage limits in force).
0 Normal operation.
12 RAMP_HOLD 1 Halt ramping (Ramp Function Generator output held).
0 Normal operation.
13 RAMP_IN_ZERO 1 Force Ramp Function Generator input to zero.
0 Normal operation.
14 REQ_LOCAL_LO
CK
1 Not yet implemented.
0 Not yet implemented.
15 Reserved for
TORQ_LIM_PAIR
_2
Not yet implemented.
16 FB_LOCAL_CTL 1 Local mode for reference from the fieldbus is requested.
Steal control from the active source.
0(no op)
17 FB_LOCAL_REF 1 Local mode for reference from the fieldbus is requested.
Steal reference from the active source.
0(no op)
18 Reserved for
RUN_DISABLE_1
Not yet implemented.
19 Reserved
20 Reserved
21 Reserved
22 USER_0 Writable control bits that can be combined with drive logic
for application-specific functionality.
23 USER_1
24 USER_2
25 USER_3
Bit Name Value State/Description
