234 Parameters
Torque Fieldbus uses torque reference scaling. Torque reference
scaling is defined by the used fieldbus profile (e.g. with ABB
Drives Profile integer value 10000 corresponds to 100%
torque value). Signal 01.06 Motor torque is sent to the
fieldbus as an actual value. See the User’s Manual of the
appropriate fieldbus adapter module.
1
Speed Fieldbus uses speed reference scaling. Speed reference
scaling is defined by the used fieldbus profile (e.g. with ABB
Drives Profile integer value 20000 corresponds to parameter
19.01 Speed scaling value). Signal 01.01 Motor speed rpm is
sent to the fieldbus as an actual value. See the User’s Manual
of the appropriate fieldbus adapter module.
2
50.05 Fb ref2 modesel Selects the fieldbus reference FBA REF2 scaling.
See parameter 50.04 Fb ref1 modesel.
Raw data See parameter 50.04 Fb ref1 modesel.0
Torque See parameter 50.04 Fb ref1 modesel.1
Speed See parameter 50.04 Fb ref1 modesel.2
50.06 Fb act1 tr src Selects the source for fieldbus actual value 1 when parameter
50.04 Fb ref1 modesel / 50.05 Fb ref2 modesel is set to Raw
data.
Pointer Value pointer setting (see Terms and abbreviations on page
102).
-
50.07 Fb act2 tr src Selects the source for fieldbus actual value 2 when parameter
50.04 Fb ref1 modesel / 50.05 Fb ref2 modesel is set to Raw
data.
Pointer Value pointer setting (see Terms and abbreviations on page
102).
-
50.08 Fb sw b12 src Selects the source for freely programmable fieldbus status
word bit 28 (02.24 FBA main sw bit 28). Note that this
functionality may not be supported by the fieldbus
communication profile.
Const Bit pointer setting (see Terms and abbreviations on page
102).
-
Pointer
50.09 Fb sw b13 src Selects the source for freely programmable fieldbus status
word bit 29 (02.24 FBA main sw bit 29). Note that this
functionality may not be supported by the fieldbus
communication profile.
Const Bit pointer setting (see Terms and abbreviations on page
102).
-
Pointer
50.10 Fb sw b14 src Selects the source for freely programmable fieldbus status
word bit 30 (02.24 FBA main sw bit 30). Note that this
functionality may not be supported by the fieldbus
communication profile.
Const Bit pointer setting (see Terms and abbreviations on page
102).
-
Pointer
50.11 Fb sw b15 src Selects the source for freely programmable fieldbus status
word bit 31 (02.24 FBA main sw bit 31). Note that this
functionality may not be supported by the fieldbus
communication profile.
Const Bit pointer setting (see Terms and abbreviations on page
102).
-
Pointer
No. Name/Value Description FbEq
