276 Additional parameter data
22.12 Em stop time REAL 32 0…1800 s 3.000 s
23 Speed ctrl
23.01 Proport gain REAL 16 0…200 - 10.00
23.02 Integration time REAL 32 0…600 s 0.500 s
23.03 Derivation time REAL 16 0…10 s 0.000 s
23.04 Deriv filt time REAL 16 0…1000 ms 8.0 ms
23.05 Acc comp DerTime REAL 32 0…600 s 0.00 s
23.06 Acc comp Ftime REAL 16 0…1000 ms 8.0 ms
23.07 Speed err Ftime REAL 16 0…1000 ms 0.0 ms
23.08 Speed additive Val pointer 32 - - Zero
23.09 Max torq sp ctrl REAL 16 -1600…1600 % 300.0%
23.10 Min torq sp ctrl REAL 16 -1600…1600 % -300.0%
23.11 SpeedErr winFunc enum 16 0…2 - Disabled
23.12 SpeedErr win hi REAL 16 0…3000 rpm 0 rpm
23.13 SpeedErr win lo REAL 16 0…3000 rpm 0 rpm
23.14 Drooping rate REAL 16 0…100 % 0.00%
23.15 PI adapt max sp REAL 16 0…30000 rpm 0 rpm
23.16 PI adapt min sp REAL 16 0…30000 rpm 0 rpm
23.17 Pcoef at min sp REAL 16 0…10 - 1.000
23.18 Icoef at min sp REAL 16 0…10 - 1.000
23.20 PI tune mode enum 16 0…4 - Done
23.21 Tune bandwidth REAL 16 0…2000 Hz 100.00 Hz
23.22 Tune damping REAL 16 0…200 - 1.5
24 Torque ref
24.01 Torq ref1 sel Val pointer 32 - - AI2 scaled
24.02 Torq ref add sel Val pointer 32 - - Zero
24.03 Maximum torq ref REAL 16 0…1000 % 300.0%
24.04 Minimum torq ref REAL 16 -1000…0 % -300.0%
24.05 Load share REAL 16 -8…8 - 1.000
24.06 Torq ramp up UINT32 32 0…60 s 0.000 s
24.07 Torq ramp down UINT32 32 0…60 s 0.000 s
25 Critical speed
25.01 Crit speed sel enum 16 0…1 - Disable
25.02 Crit speed1 lo REAL 16 -30000…30000 rpm 0 rpm
25.03 Crit speed1 hi REAL 16 -30000…30000 rpm 0 rpm
25.04 Crit speed2 lo REAL 16 -30000…30000 rpm 0 rpm
25.05 Crit speed2 hi REAL 16 -30000…30000 rpm 0 rpm
25.06 Crit speed3 lo REAL 16 -30000…30000 rpm 0 rpm
25.07 Crit speed3 hi REAL 16 -30000…30000 rpm 0 rpm
No. Name Type
Data
len.
Range Unit
Default
(Factory macro)
