ABB ACS850 - Page 277

Additional parameter data 277
26 Constant speeds
26.01 Const speed func Pb 16 0b00…0b11 - 0b00
26.02 Const speed sel1 Bit pointer 32 - - C.FALSE
26.03 Const speed sel2 Bit pointer 32 - - C.FALSE
26.04 Const speed sel3 Bit pointer 32 - - C.FALSE
26.06 Const speed1 REAL 16 -30000…30000 rpm 0 rpm
26.07 Const speed2 REAL 16 -30000…30000 rpm 0 rpm
26.08 Const speed3 REAL 16 -30000…30000 rpm 0 rpm
26.09 Const speed4 REAL 16 -30000…30000 rpm 0 rpm
26.10 Const speed5 REAL 16 -30000…30000 rpm 0 rpm
26.11 Const speed6 REAL 16 -30000…30000 rpm 0 rpm
26.12 Const speed7 REAL 16 -30000…30000 rpm 0 rpm
27 Process PID
27.01 PID setpoint sel Val pointer 32 - - AI1 scaled
27.02 PID fbk func enum 16 0…8 - Act1
27.03 PID fbk1 src Val pointer 32 - - AI2 scaled
27.04 PID fbk2 src Val pointer 32 - - AI2 scaled
27.05 PID fbk1 max REAL 32 -32768…32768 - 100.00
27.06 PID fbk1 min REAL 32 -32768…32768 - -100.00
27.07 PID fbk2 max REAL 32 -32768…32768 - 100.00
27.08 PID fbk2 min REAL 32 -32768…32768 - -100.00
27.09 PID fbk gain REAL 16 -32.768 … 32.767 - 1.000
27.10 PID fbk ftime REAL 16 0…30 s 0.040 s
27.12 PID gain REAL 16 0…100 - 1.00
27.13 PID integ time REAL 16 0…320 s 60.00 s
27.14 PID deriv time REAL 16 0…10 s 0.00 s
27.15 PID deriv filter REAL 16 0…10 s 1.00 s
27.16 PID error inv Bit pointer 32 - - C.FALSE
27.17 PID mode enum 16 0…2 - Direct
27.18 PID maximum REAL 32 -32768…32768 - 100.0
27.19 PID minimum REAL 32 -32768…32768 - -100.0
27.22 Sleep mode enum 16 0…2 - No
27.23 Sleep level REAL 32 -32768…32768 rpm 0.0 rpm
27.24 Sleep delay UINT32 32 0…360 s 0.0 s
27.25 Wake up level REAL 32 0…32768 - 0.0
27.26 Wake up delay UINT32 32 0…360 s 0.0 s
27.27 Sleep ena Bit pointer 32 - - C.FALSE
30 Fault functions
30.01 External fault Bit pointer 32 - - C.TRUE
30.02 Speed ref safe REAL 16 -30000…30000 rpm 0 rpm
No. Name Type
Data
len.
Range Unit
Default
(Factory macro)
