ABB ACS850 - Page 278

278 Additional parameter data
30.03 Local ctrl loss enum 16 0…3 - Fault
30.04 Mot phase loss enum 16 0…1 - Fault
30.05 Earth fault enum 16 0…2 - Fault
30.06 Suppl phs loss enum 16 0…1 - Fault
30.07 Sto diagnostic enum 16 1…4 - Fault
30.08 Cross connection enum 16 0…1 - Fault
30.09 Stall function Pb 16 0b000…0b111 - 0b111
30.10 Stall curr lim REAL 16 0…1600 % 200.0%
30.11 Stall freq hi REAL 16 0.5 … 1000 Hz 15.0 Hz
30.12 Stall time UINT32 16 0…3600 s 20 s
31 Motor therm prot
31.01 Mot temp1 prot enum 16 0…2 - No
31.02 Mot temp1 src enum 16 0…12 - Estimated
31.03 Mot temp1 almLim INT32 16 0…200 °C 90 °C
31.04 Mot temp1 fltLim INT32 16 0…200 °C 110 °C
31.05 Mot temp2 prot enum 16 0…2 - No
31.06 Mot temp2 src enum 16 0…12 - Estimated
31.07 Mot temp2 almLim INT32 16 0…200 °C 90 °C
31.08 Mot temp2 fltLim INT32 16 0…200 °C 110 °C
31.09 Mot ambient temp INT32 16 -60…100 °C 20 °C
31.10 Mot load curve INT32 16 50…150 % 100%
31.11 Zero speed load INT32 16 50…150 % 100%
31.12 Break point INT32 16 0.01…500 Hz 45.00 Hz
31.13 Mot nom tempRise INT32 16 0…300 °C 80 °C
31.14 Mot therm time INT32 16 100…10000 s 256 s
32 Automatic reset
32.01 Autoreset sel Pb 16 0b000000…0b111111 - 0b000000
32.02 Number of trials UINT32 16 0…5 - 0
32.03 Trial time UINT32 16 1…600 s 30.0 s
32.04 Delay time UINT32 16 0…120 s 0.0 s
33 Supervision
33.01 Superv1 func enum 16 0…4 - Disabled
33.02 Superv1 act Val pointer 32 - - Speed rpm
33.03 Superv1 hi REAL 32 -32768…32768 - 0.00
33.04 Superv1 lo REAL 32 -32768…32768 - 0.00
33.05 Superv2 func enum 16 0…4 - Disabled
33.06 Superv2 act Val pointer 32 - - Current
33.07 Superv2 hi REAL 32 -32768…32768 - 0.00
33.08 Superv2 lo REAL 32 -32768…32768 - 0.00
33.09 Superv3 func enum 16 0…4 - Disabled
No. Name Type
Data
len.
Range Unit
Default
(Factory macro)
