ABB ACS850 - Page 279

Additional parameter data 279
33.10 Superv3 act Val pointer 32 - - Torque
33.11 Superv3 hi REAL 32 -32768…32768 - 0.00
33.12 Superv3 lo REAL 32 -32768…32768 - 0.00
34 User load curve
34.01 Overload func Pb 16 0b000000…0b111111 - 0b000000
34.02 Underload func Pb 16 0b0000…0b1111 - 0b0000
34.03 Load freq1 REAL 16 1…500 Hz 5 Hz
34.04 Load freq2 REAL 16 1…500 Hz 25 Hz
34.05 Load freq3 REAL 16 1…500 Hz 43 Hz
34.06 Load freq4 REAL 16 1…500 Hz 50 Hz
34.07 Load freq5 REAL 16 1…500 Hz 500 Hz
34.08 Load low lim1 REAL 16 0…1600 % 10%
34.09 Load low lim2 REAL 16 0…1600 % 15%
34.10 Load low lim3 REAL 16 0…1600 % 25%
34.11 Load low lim4 REAL 16 0…1600 % 30%
34.12 Load low lim5 REAL 16 0…1600 % 30%
34.13 Load high lim1 REAL 16 0…1600 % 300%
34.14 Load high lim2 REAL 16 0…1600 % 300%
34.15 Load high lim3 REAL 16 0…1600 % 300%
34.16 Load high lim4 REAL 16 0…1600 % 300%
34.17 Load high lim5 REAL 16 0…1600 % 300%
34.18 Load integ time UINT32 16 0…10000 s 100 s
34.19 Load cool time UINT32 16 0…10000 s 20 s
34.20 Underload time UINT32 16 0…10000 s 10 s
35 Process variable
35.01 Signal1 param Val pointer 32 - - Speed %
35.02 Signal1 max REAL 32 -32768…32768 - 300.000
35.03 Signal1 min REAL 32 -32768…32768 - -300.000
35.04 Proc var1 dispf enum 16 0…5 - 3
35.05 Proc var1 unit enum 16 0…98 - 4
35.06 Proc var1 max REAL 32 -32768…32768 - 300.000
35.07 Proc var1 min REAL 32 -32768…32768 - -300.000
35.08 Signal2 param Val pointer 32 - - Current %
35.09 Signal2 max REAL 32 -32768…32768 - 300.000
35.10 Signal2 min REAL 32 -32768…32768 - -300.000
35.11 Proc var2 dispf enum 16 0…5 - 3
35.12 Proc var2 unit enum 16 0…98 - 4
35.13 Proc var2 max REAL 32 -32768…32768 - 300.000
35.14 Proc var2 min REAL 32 -32768…32768 - -300.000
35.15 Signal3 param Val pointer 32 - - Torque
No. Name Type
Data
len.
Range Unit
Default
(Factory macro)
