280 Additional parameter data
35.16 Signal3 max REAL 32 -32768…32768 - 300.000
35.17 Signal3 min REAL 32 -32768…32768 - -300.000
35.18 Proc var3 dispf enum 16 0…5 - 3
35.19 Proc var3 unit enum 16 0…98 - 4
35.20 Proc var3 max REAL 32 -32768…32768 - 300.000
35.21 Proc var3 min REAL 32 -32768…32768 - -300.000
36 Timed functions
36.01 Timers enable Bit pointer 32 - - C.FALSE
36.02 Timers mode Pb 16 0b0000…0b1111 - 0b0000
36.03 Start time1 UINT32 32 00:00:00 … 24:00:00 - 00:00:00
36.04 Stop time1 UINT32 32 00:00:00 … 24:00:00 - 00:00:00
36.05 Start day1 enum 16 1…7 - Monday
36.06 Stop day1 enum 16 1…7 - Monday
36.07 Start time2 UINT32 32 00:00:00 … 24:00:00 - 00:00:00
36.08 Stop time2 UINT32 32 00:00:00 … 24:00:00 - 00:00:00
36.09 Start day2 enum 16 1…7 - Monday
36.10 Stop day2 enum 16 1…7 - Monday
36.11 Start time3 UINT32 32 00:00:00 … 24:00:00 - 00:00:00
36.12 Stop time3 UINT32 32 00:00:00 … 24:00:00 - 00:00:00
36.13 Start day3 enum 16 1…7 - Monday
36.14 Stop day3 enum 16 1…7 - Monday
36.15 Start time4 UINT32 32 00:00:00 … 24:00:00 - 00:00:00
36.16 Stop time4 UINT32 32 00:00:00 … 24:00:00 - 00:00:00
36.17 Start day4 enum 16 1…7 - Monday
36.18 Stop day4 enum 16 1…7 - Monday
36.19 Boost signal Bit pointer 32 - - C.FALSE
36.20 Boost time UINT32 32 00:00:00 … 24:00:00 - 00:00:00
36.21 Timed func1 Pb 16 0b00000…0b11111 - 0b00000
36.22 Timed func2 Pb 16 0b00000…0b11111 - 0b00000
36.23 Timed func3 Pb 16 0b00000…0b11111 - 0b00000
36.24 Timed func4 Pb 16 0b00000…0b11111 - 0b00000
38 Flux ref
38.01 Flux ref REAL 16 0…200 % 100%
38.03 U/f curve func enum 16 0…2 - Linear
38.04 U/f curve freq1 REAL 16 1…500 % 10%
38.05 U/f curve freq2 REAL 16 1…500 % 30%
38.06 U/f curve freq3 REAL 16 1…500 % 50%
38.07 U/f curve freq4 REAL 16 1…500 % 70%
38.08 U/f curve freq5 REAL 16 1…500 % 90%
38.09 U/f curve volt1 REAL 16 0…200 % 20%
No. Name Type
Data
len.
Range Unit
Default
(Factory macro)
