ABB ACS850 - Page 281

Additional parameter data 281
38.10 U/f curve volt2 REAL 16 0…200 % 40%
38.11 U/f curve volt3 REAL 16 0…200 % 60%
38.12 U/f curve volt4 REAL 16 0…200 % 80%
38.13 U/f curve volt5 REAL 16 0…200 % 100%
38.16 Flux ref pointer Val pointer 32 - - P.38.01
40 Motor control
40.01 Motor noise enum 16 0…2 - Default
40.03 Slip gain REAL24 32 0…200 % 100%
40.04 Voltage reserve REAL24 32 -4…50 % -1%
40.06 Force open loop enum 16 0…1 - False
40.07 IR-compensation REAL24 32 0…50 % 0.00%
40.10 Flux braking enum 16 0…2 - Disabled
42 Mech brake ctrl
42.01 Brake ctrl enum 16 0…2 - No
42.02 Brake acknowl Bit pointer 32 - - C.FALSE
42.03 Open delay UINT32 16 0…5 s 0.00 s
42.04 Close delay UINT32 16 0…60 s 0.00 s
42.05 Close speed REAL 16 0…1000 rpm 100.0 rpm
42.06 Close cmd delay UINT32 16 0…10 s 0.00 s
42.07 Reopen delay UINT32 16 0…10 s 0.00 s
42.08 Brake open torq REAL 16 -1000…1000 % 0.0%
42.09 Open torq src Val pointer 32 - - P. 4 2. 08
42.10 Brake close req Bit pointer 32 - - C.FALSE
42.11 Brake hold open Bit pointer 32 - - C.FALSE
42.12 Brake fault func enum 16 0…2 - Fault
42.13 Close flt delay UINT32 16 0…600 s 0.00 s
42.14 Extend run time UINT32 16 0…3600 s 0.00 s
44 Maintenance
44.01 Ontime1 func Pb 16 0b00…0b11 - 0b01
44.02 Ontime1 src Bit pointer 32 - - Running
44.03 Ontime1 limit UINT32 32 0…2147483647 s 36000000 s
44.04 Ontime1 alm sel enum 16 0…6 - Mot bearing
44.05 Ontime2 func Pb 16 0b00…0b11 - 0b01
44.06 Ontime2 src Bit pointer 32 - - Charged
44.07 Ontime2 limit UINT32 32 0…2147483647 s 15768000 s
44.08 Ontime2 alm sel enum 16 0…6 - Device clean
44.09 Edge count1 func Pb 16 0b00…0b11 - 0b01
44.10 Edge count1 src Bit pointer 32 - - Charged
44.11 Edge count1 lim UINT32 32 0…2147483647 - 5000
44.12 Edge count1 div UINT32 32 0…2147483647 - 1
No. Name Type
Data
len.
Range Unit
Default
(Factory macro)
