Parameters 211
35.10 Signal2 min Defines the real value of the selected signal that corresponds
to the minimum display value defined by parameter 35.14
Proc var2 min. See diagram at parameter 35.09 Signal2 max.
-32768…32768 Real signal value corresponding to minimum process variable
2 value.
1 = 1
35.11 Proc var2 dispf Scaling for process variable 2. This setting also scales the
value for fieldbus.
01 = 1 0
1 10 = 1 1
2 100 = 1 2
3 1000 = 1 3
4 10000 = 1 4
5 100000 = 1 5
35.12 Proc var2 unit Specifies the unit for parameter 04.07 Process var2 (process
variable 2).
0…98 See parameter 35.05 Proc var1 unit.1 = 1
35.13 Proc var2 max Maximum value for process variable 2. See diagram at
parameter 35.09 Signal2 max.
-32768…32768 Maximum value for process variable 2. 1 = 1
35.14 Proc var2 min Minimum value for process variable 2. See diagram at
parameter 35.09 Signal2 max.
-32768…32768 Minimum value for process variable 2. 1 = 1
35.15 Signal3 param Selects a signal to be provided as parameter 04.08 Process
var3.
Speed rpm 01.01 Motor speed rpm (see page 103). 1073742081
Speed % 01.02 Motor speed % (see page 103). 1073742082
Frequency 01.03 Output frequency (see page 103). 1073742083
Current 01.04 Motor current (see page 103). 1073742084
Current % 01.05 Motor current % (see page 103). 1073742085
Torque 01.06 Motor torque (see page 103). 1073742086
Dc-voltage 01.07 Dc-voltage (see page 103). 1073742087
Power inu
01.22 Power inu out (see page 103). 1073742102
Power motor 01.23 Motor power (see page 103). 1073742103
SpRef unramp 03.03 SpeedRef unramp (see page 114). 1073742595
SpRef ramped 03.05 SpeedRef ramped (see page 114). 1073742597
SpRef used 03.06 SpeedRef used (see page 114). 1073742598
TorqRef used 03.14 Torq ref used (see page 115). 1073742606
Process act 04.03 Process act (see page 115). 1073742851
Proc PID out 04.05 Process PID out (see page 115). 1073742853
Pointer Value pointer setting (see Terms and abbreviations on page
102).
-
No. Name/Value Description FbEq
