342 Control through a fieldbus adapter
After the module configuration parameters have been set, the drive control
parameters (see section Setting the drive control parameters below) must be
checked and adjusted when necessary.
The new settings will take effect when the drive is powered up the next time, or when
parameter 51.27 FBA par refresh is activated.
51.29 Drive type
code
– Displays the drive type code of the fieldbus
adapter module mapping file stored in the
memory of the drive.
51.30 Mapping file
ver
– Displays the fieldbus adapter module
mapping file revision stored in the memory
of the drive.
51.31 D2FBA comm
sta
– Displays the status of the fieldbus adapter
module communication.
51.32 FBA comm
sw ver
– Displays the common program revision of
the adapter module.
51.33 FBA appl sw
ver
– Displays the application program revision of
the adapter module.
Note: In the User’s Manual of the fieldbus adapter module, the parameter group number is 1
or A for parameters 51.01…51.26.
TRANSMITTED DATA SELECTION (see also page 237)
52.01 FBA data in1
… 52.12 FBA data
in12
4…6
14…16
101…9999
Defines the data transmitted from drive to
fieldbus controller.
Note: If the selected data is 32 bits long,
two parameters are reserved for the
transmission.
53.01 FBA data out1
… 53.12 FBA data
out12
1…3
11…13
1001…9999
Defines the data transmitted from fieldbus
controller to drive.
Note: If the selected data is 32 bits long,
two parameters are reserved for the
transmission.
Note: In the User’s Manual of the fieldbus adapter module, the parameter group number is 2
or B for parameters 52.01…52.12 and 3 or C for parameters 53.01…53.12.
Parameter Setting for
fieldbus control
Function/Information
