4.4.2. Draining of water separation filter
3HAC030005-001 Revision: -160
© Copyright 2006 ABB. All rights reserved.
4.4.2. Draining of water separation filter
General
This section describes:
• air filter chage in the vacuum system
• emptying water separation filter
DANGER!
Turn off all electrical power, hydraulic and pneumatic pressure supplies to the robot!
Also read the safety sections:
• Safety risks related to pneumatic/hydraulic systems on page 18
• Risks associated with live electric parts on page 20
• Safety risks during installation and service work on robot on page 15
Location
xx0700000544
A Air filter (comp)
B Air filter (Vac)
C Water separation bottom nipple
