4.5 Lower arm
4.5.1 Replacing the lower arm
Location of lower arm
Type C
The lower arm is located as shown in the figure.
xx1200000636
Upper armA
Axis-3 gearboxB
Continues on next page
268 3HAC033453-001 Revision: H
© Copyright 2009-2013 ABB. All rights reserved.
4 Repair
4.5.1 Replacing the lower arm
