4.3.2 Configuring camera
Introduction
Note
If any firewall or antivirus software is installed, add pickmasteru.exe,
sshd.exe, and visionclient. exe to the white list.
Otherwise the PickMaster PowerPac cannot connect Runtime and the vision
function cannot work normally.
Cameras together with vision models are used to locate objects in a specific area.
When a camera is created in the tree view, it is not connected to any physical
camera. This must be done manually in the camera configuration dialog box. The
camera in the tree view is configured to use one specific physical camera. The
camera should also be configured to give an optimal image.
To configure a camera.
1 Right-click the camera in the tree view Cell and select Configuration.
xx1800001463
The Camera Configuration dialog and the Image dialog are opened.
xx1800001464
Continues on next page
Application manual - PickMaster® Twin - PowerPac 181
3HAC064218-001 Revision: B
© Copyright 2021 ABB. All rights reserved.
4 Working with PickMaster PowerPac
4.3.2 Configuring camera
