Note/IllustrationAction
xx1900000650
Click Defineto open the train shape of the
item1.
33
xx1800001708
Drag the train shape center point to the
item's center.
34
xx1900000651
Click Train to open the train shape of the
item1.
35
Click OK to close and save the PatMax
model.
36
Click Ok to close and save the Item1
setting.
37
Production
Note/IllustrationAction
xx1800001716
Click to select the Recipe in the tree view
Cell.
1
xx1800001717
On the Production ribbon-tab, click Pro-
duction.
2
