3.17.9.1 Function block
IN1
IN2 OUT2
IN3
IN4
OUT3
OUT4
OUT1
MVI4GAPC
Figure 94: Function block
3.17.9.2 Functionality
The integer value move function MVI4GAPC is used for creation of the events from
the integer values. The integer input value is received via IN1...4 input. The integer
output value is available on OUT1...4 output.
The integer input range is from -2147483648 to 2147483647.
3.17.9.3 Signals
Table 177: MVI4GAPC Input signals
Name Type Default Description
IN1 INT32 0 Integer input value 1
IN2 INT32 0 Integer input value 2
IN3 INT32 0 Integer input value 3
IN4 INT32 0 Integer input value 4
Table 178: MVI4GAPC Output signals
Name Type Description
OUT1 INT32 Integer output value 1
OUT2 INT32 Integer output value 2
OUT3 INT32 Integer output value 3
OUT4 INT32 Integer output value 4
3.17.10 Analog value scaling SCA4GAPC
Basic functions
1MRS758755 C
162 REC615 & RER615
Technical Manual
