3.1.2 Analog input settings, residual current
Table 8: Analog input settings, residual current
Parameter Values (Range) Unit Step Default Description
Primary current 1.0...6000.0 A 0.1 100.0 Primary current
Secondary current
1=0.2A
2=1A
3=5A
2=1A Secondary current
Amplitude Corr 0.9000...1.1000 0.0001 1.0000 Amplitude correc-
tion
Reverse polarity
0=False
1=True
0=False Reverse the polari-
ty of the residual
CT
Angle correction -20.0000...20.0000 deg 0.0001 0.0000 Angle correction
factor
3.1.3 Analog input settings, phase voltages
Table 9: nalog input settings, phase voltages
Parameter Values (Range) Unit Step Default Description
Primary voltage 0.100...440.000 kV 0.001 11.547 Primary voltage
Secondary volt-
age
60...210 V 1 100 Secondary voltage
Amplitude Corr 0.9000...1.1000 0.0001 1.0000 Amplitude correc-
tion
Angle correction -20.0000...20.000
0
deg 0.0001 0.0000 Angle correction
factor
3.1.4 Analog input settings, residual voltage
Table 10: Analog input settings, residual voltage
Parameter Values (Range) Unit Step Default Description
Primary voltage 0.100...440.000
1
kV 0.001 20.000 Primary rated voltage
Secondary voltage 60...210 V 1 100 Secondary rated voltage
VT connection 1=Wye
2=Delta
3=U12
4=UL1
2=Delta Voltage transducer measurement
connection
Table continues on the next page
1
In 9-2 applications, Primary voltage maximum is limited to 126 kV.
