Parameter Values (Range) Unit Step Default Description
Description SPCLGAPC1 Output
15
Generic control point description
Operation mode
0=Pulsed
1=Toggle/Persistent
-1=Off
-1=Off Operation mode for generic con-
trol point
Pulse length 10...3600000 ms 10 1000 Pulse length for pulsed operation
mode
Description SPCLGAPC1 Output
16
Generic control point description
3.17.15 Programmable buttons (4 buttons) FKEY4GGIO
3.17.15.1 Identification
Function description IEC 61850
identification
IEC 60617
identification
ANSI/IEEE C37.2
device number
Programmable but-
tons (4 buttons)
FKEY4GGIO FKEY4GGIO FKEY4GGIO
3.17.15.2 Function block
FKEY4GGIO
K2
K1
K3
K4
L2
L1
L3
L4
Figure 105: Function block
3.17.15.3 Functionality
The Programmable buttons function FKEY4GGIO is a simple interface between the
panel and the application. The user input from the buttons available on the front
panel is transferred to the assigned functionality and the corresponding LED is
turned ON or OFF for indication. The behavior of each function key in the specific
application is configured by connection with other application functions. This gives
maximum flexibility.
3.17.15.4 Operation principle
Inputs L1...L4 represent the LEDs on the relay's LHMI. When an input is set to
TRUE, the corresponding LED is lit. When a function key on the LHMI is pressed, the
corresponding output K1...K4 is set to TRUE.
Each function key has settable text descriptions for the on and off states. The
visibility of function key text descriptions on the LHMI can be selected with setting
parameter Function key text visibility .
1MRS758755 C
Basic functions
REC615 & RER615
Technical Manual
187
