Name Type Default Description
RECL_ON BOOLEAN 0=False Level sensitive signal
for allowing (high) /
not allowing (low) re-
closing
SYNC BOOLEAN 0=False Synchronizing check
fulfilled
9.4.7.2 DARREC Output signals
Table 687: DARREC Output signals
Name Type Description
OPEN_CB BOOLEAN Open command for circuit
breaker
CLOSE_CB BOOLEAN Close (reclose) command for
circuit breaker
CMD_WAIT BOOLEAN Wait for master command
INPRO BOOLEAN Reclosing shot in progress,
activated during dead time
LOCKED BOOLEAN Signal indicating that AR is
locked out
PROT_CRD BOOLEAN A signal for coordination be-
tween the AR and the protec-
tion
UNSUC_RECL BOOLEAN Indicates an unsuccessful re-
closing sequence
AR_ON BOOLEAN Autoreclosing allowed
READY BOOLEAN Indicates that the AR is ready
for a new sequence, i.e. the
CB_READY input equals TRUE
ACTIVE BOOLEAN Reclosing sequence is in pro-
gress
9.4.8 Settings
9.4.8.1 DARREC Non group settings
Table 688: DARREC Non group settings (Basic)
Parameter Values (Range) Unit Step Default Description
Operation
1=on
5=off
1=on Operation Off/On
Reclosing opera-
tion
1=Off
2=External Ctl
1=Off Reclosing opera-
tion (Off, External
Ctl / On)
Table continues on the next page
