ABB Relion REC615 - Page 688

Name Type Values (Range) Unit Description
FRQ_OPR_AL BOOLEAN
0=False
1=True
Frequent opera-
tion counter
alarm
STATUS Enum
-1=Not defined
1=Ready
2=InProgress
3=Successful
4=WaitingFor-
Trip
5=TripFromPro-
tection
6=FaultDisap-
peared
7=WaitToCom-
plete
8=CBclosed
9=CycleUnsuc-
cessful
10=Unsuccessful
11=Aborted
AR status signal
for IEC61850
INPRO_1 BOOLEAN
0=False
1=True
Reclosing shot in
progress, shot 1
INPRO_2 BOOLEAN
0=False
1=True
Reclosing shot in
progress, shot 2
INPRO_3 BOOLEAN
0=False
1=True
Reclosing shot in
progress, shot 3
INPRO_4 BOOLEAN
0=False
1=True
Reclosing shot in
progress, shot 4
INPRO_5 BOOLEAN
0=False
1=True
Reclosing shot in
progress, shot 5
DISCR_INPRO BOOLEAN
0=False
1=True
Signal indicating
that discrimina-
tion time is in
progress
CUTOUT_INPRO BOOLEAN
0=False
1=True
Signal indicating
that cut-out time
is in progress
Table continues on the next page
Control functions 1MRS758755 C
688 REC615 & RER615
Technical Manual
