SensyMaster FMT430, FMT450 THERMAL MASS FLOWMETER | OI/FMT430/450-EN REV. B 103
Menu / parameter
Description
Device Info / ...Sensor /
...Application 1
...
Device Info / ...Sensor / ...Application 8
Description
Display of the name of the application 1
... 8.
...A1...Flow meas.
...
...A8...Flow meas.
Selection of submenu ‘
...A1...Flow meas.’ ... ‘...A8...Flow meas.’ using .
...A1...Temp. meas.
...
...A8...Temp. meas.
Selection of submenu ‘
...A1...Temp. meas.’ ... ‘...A8...Temp. meas.’ using .
...A1...Pipe type
...
...A8...Pipe type
Selection of submenu ‘
...A1...Pipe type’ ... ‘...A8...Pipe type’ using .
...A1...Gas data
...
...A8...Gas data
Selection of submenu ‘
...A1...Gas data’ ... ‘...A8...Gas data’ using .
...A1...Field Optim.
...
...A1...Field Optim.
Selection of submenu ‘
...A1...Field Optim.’ ... ‘...A8...Field Optim.’ using .
Device Info / ...Sensor / ...Application 1 /
...A1...Flow meas.
...
Device Info / ...Sensor / ...Application 8 /
...A8...Flow meas.
Qm Max. DN
Display of the maximum mass flow for the selected nominal diameter.
Qm Max
Display of the upper range
value for the mass flow.
Qm Min
Display of the lower range value for the mass flow.
Qv@ Max. DN
Display of the maximum standard volume flow for the selected nominal diameter.
Qv@ Max
Display of the upper range value for the standard volume flow.
Qv@ Mi
n
Display of the lower range value for the standard volume flow.
Damping Q
Display of the damping for flow measurement.
Low Flow Cut Off
Display of the switching threshold (0
to 10 %) for the low flow cut-off.
LowFlow Hysteresis
Display of the
hysteresis (0 to 50 %) for the low flow cut-off.
