104 SensyMaster FMT430, FMT450 THERMAL MASS FLOWMETER | OI/FMT430/450-EN REV. B
… 9 Operation
… Parameter descriptions
Menu / parameter
Description
Device Info / ...Sensor / ...Application 1 /
...A1...Temp. meas.
...
Device Info / ...Sensor / ...Application 8 / ...A8...Temp. meas.
Tm Max
Display of the upper range value for the measuring medium temperature.
Tm Min
Display of the lower range value for the measuring medium temperature.
Damping Tm
Display of the damping for temperature measurement.
Device Info / ...Sensor / ...Application 1 /
...A1...Pipe type
...
Device Info / ...Sensor / ...Application 8 / ...A8...Pipe type
Shape and probe pos.
Display of the piping form and sensor position.
Inside diameter
Display of the inside diameter of the piping.
Duct inner height
Display of the inside height of the
channel with rectangular cross-section.
Insertion depth
Display of the insertion depth of the sensor.
Duct inner width
Display of the inside width of the channel with rectangular cross
-section.
Device Info / ...Sensor / ...Application 1 /
...A1...Gas data
...
Device Info / ...Sensor / ...Application 8 /
...A8...Gas data
Mean Operating Temp.
Display of the average measuring medium temperature.
Mean Operating Press
Display of the average measuring medium pressure.
Gas Type 1
...
Gas Type 10
Display of gas type for gas components 1
to 10 of a gas mix.
See table
Available gas types on page 97.
Concentr. Gas Type 1
...
Concentr.Gas Type 10
Display of concentration in % for gas components 1
to 10 of a gas mix.
Device Info / ...Sensor / ...Application 1 /
...A1...Field Optim.
...
Device Info / ...Sensor / ...Application 8 / ...A8...Field Optim.
Offset Qm
Offset correction of the flow rate measured value.
Corr.Factor Qm
Correction factor for the flow measured value.
