SensyMaster FMT430, FMT450 THERMAL MASS FLOWMETER | OI/FMT430/450-EN REV. B 115
Input/Output / ...Dig.Out 41/42 / ...Binary Out 41/42
Selection of binary output function.
Alarm: The binary output indicates an active alarm. The alarm is selected in the ‘„...Alarm Cfg. 41/42’ menu.
Batch End: The binary output is activated when the set fill quantity is reached (only if the FillMass function is activated).
Select switching properties for the binary output.
Active High: Normally open
• Active Low: Normally closed
Input/Output / ...Dig.Out 41/42 /
...Alarm Cfg. 41/42
Selection of error messages signaled via the binary output 41
/ 42.
Signal Source Binary" has been set to “Alarm“.
Volumeflow Max
Input/Output / ...Dig.Out 51/52
Selection of the operating mode for the digital output 51
/ 52. The following operating mode Pulse 41/42 <)90°, Pulse 41/42
“ is only available if the digital output 41 / 42 has been configured as a pulse output.
Off: Digital output deactivated.
Binary: Digital output configured as a binary output (for function see parameter ‘...Binary Out 51/52’).
Frequency: Digital output 51 / 52 as a frequency output. In frequency mode, a frequency is issued that is proportional to
the flow rate.
Pulse 41/42 <)90°: Output of the same pulses as for digital output 41 / 42, phase shifted by 90°.
• Pulse 41/42 <)180°: Output of the same pulses as for digital output 41 / 42, phase shifted by 180°
...Puls.Out 51/52’ using .
...Freq.Out 51/52’ using .
Only available if ‘Mode’ Frequency has been selected.
...Binary Out 51/52’ using .
Mode’ Binary has been selected.
...Alarm Cfg. 51/52’ using .
Only available if ‘Mode’ Binary has been selected.
