116 SensyMaster FMT430, FMT450 THERMAL MASS FLOWMETER | OI/FMT430/450-EN REV. B
… 9 Operation
… Parameter descriptions
Menu / parameter
Description
Input/Output / ...Dig.Out 51/52 / ...Puls.Out 51/52
Signal Source Pulse
Display of parameters that have been set in the ‘
...Puls.Out 41/42’ menu.
Quantity Pulses
Quantity Mass
Quantity Volume@
Pulse Width
Input/Output / ...Dig.Out 51/52 / ...Freq.Out 51/52
Signal Source Freq.
Selection of process variable that is issued via the frequency output.
Refer to
Available process variables on page 98.
Upper Range Value
Set the frequency range for output of the selected process variables.
•
Upper Range Value: Set the frequency for 100 % of the process variable.
• Lower Range Value: Set the frequency for 0 % of the process variable.
Lower Range Value
Input/Output / ...Dig.Out 51/52 / ...Binary Out 51/52
Signal Source Binary
Selection of binary output function.
•
Alarm: The binary output indicates an active alarm. The alarm is selected in the ‘„...Alarm Cfg. 51/52’ menu.
•
Batch End: The binary output is activated when the set fill quantity is reached (only if the FillMass function is activated).
Active Mode
Select switching properties for the binary output.
•
Active High: Normally open
• Active Low: Normally closed
Input/Output / ...Dig.Out 51/52 /
...Alarm Cfg. 51/52
General Alarm
Selection of error messages signaled via the binary output 51
/ 52.
Only if the parameter "
Signal Source Binary" has been set to “Alarm“.
Qm Massflow Max
Qm Massflow Min
Qv@ Volumeflow Max
Qv@ Volumeflow Min
Tm Temperature Max
Tm Temperature Min
Sensor Soiling
In preparation
