SensyMaster FMT430, FMT450 THERMAL MASS FLOWMETER | OI/FMT430/450-EN REV. B 77
Configuring the digital outputs
16. Use to call up the edit mode.
17. Use / to select the desired operating modeOff,
Binary, Pulse, Frequencyfor the digital output.
18. Confirm the selection with .
Dig.Out 41/42 Mode”
has been selected.
19. Use to call up the edit mode.
20. Using / , select the desired process value for
frequency output 41 / 42.
21. Confirm the selection with .
Dig.Out 41/42 Mode”
has been selected.
22. Use to call up the edit mode.
23. Using / set the frequency for 100 % of the flow rate.
24. Confirm the selection with .
Dig.Out 41/42 Mode”
has been selected.
25. Use to call up the edit mode.
26. Using / set the frequency for 0 % of the flow rate.
27. Confirm the selection with .
Dig.Out 41/42 Mode”
has been selected.
28. Use to call up the edit mode.
29. Using / , select the desired process value for pulse
output 41 / 42.
30. Confirm the selection with .
Dig.Out 41/42 Mode”
has been selected.
31. Use to call up the edit mode.
32. Use / to select the desired pulse width for the pulse
output..
33. Confirm the selection with .
Dig.Out 41/42 Mode”
has been selected.
34. Use to call up the edit mode.
35. Using / , select the desired function for binary output
41 / 42.
36. Confirm the selection with .
37. Use to call up the edit mode.
38. Use / to select the desired operating modeOff,
Binary, Frequency, Pulse 41/42 <)90°, Pulse 41/42 <)180°for
the digital output.
39. Confirm the selection with .
