Abov MC97F6108A User Manual

1. Description MC97F6108A User’s manual
12
1 Description
MC97F6108A is an advanced CMOS 8-bit microcontroller with 8Kbytes of FLASH. This is a powerful
microcontroller which provides a highly flexible and cost effective solution to many embedded control
applications.
1.1 Device overview
In this section, features of MC97F6108A and peripheral counts are introduced.
Table 1. MC97F6108A Device Features and Peripheral Counts
Peripherals
Description
Core
CPU
8-bit CISC core (M8051, 2 clocks per cycle)
Interrupt
Up to 23 peripheral interrupts supported.
 EINT0, EINT1, EINT2, PCI (4)
 Comparator output (5)
 I2C (1)
 USART (2)
 Timer (0/1/2/3) (4)
 PPG (1)
 ADC (1)
 WDT (1)
 BIT (1)
 BOD (1)
 ATP MAX/MIN (2)
Memory
ROM (FLASH)
capacity
 8Kbytes FLASH with self-read and write capability
 In-system programming (ISP)
 Endurance: 10,000times
 Retention: 10years
IRAM
256Bytes
XRAM
256Bytes
Pin change interrupt
 P1[7:0]
Pulse width modulation
 Pulse generation (by T0/T1/T2/T3)
Buzzer
8-bit × 1-ch
Minimum instruction execution
time
 125ns (@ 16MHz main clock)
Power down mode
 STOP mode
 IDLE mode
