6. Interrupt controller MC97F6108A User’s manual
60
6.12.19 Register map
Table 9. Interrupt Register Map
Name
Address
Direction
Default
Description
IE
A8H
R/W
00H
Interrupt Enable Register
IE1
A9H
R/W
00H
Interrupt Enable Register 1
IE2
AAH
R/W
00H
Interrupt Enable Register 2
IE3
ABH
R/W
00H
Interrupt Enable Register 3
IP
92H
R/W
00H
Interrupt PriorityRegister
IPH
93H
R/W
00H
Interrupt PriorityRegister High
IP1
9AH
R/W
00H
Interrupt PriorityRegister 1
IP1H
9BH
R/W
00H
Interrupt PriorityRegister 1 High
IP2
9CH
R/W
00H
Interrupt PriorityRegister 2
IP2H
9DH
R/W
00H
Interrupt PriorityRegister 2 High
IP3
9EH
R/W
00H
Interrupt PriorityRegister 3
IP3H
9FH
R/W
00H
Interrupt PriorityRegister 3 High
EIENAB
A3H
R/W
00H
External Interrupt Flag Enable Register
EIFLAG
A4H
R/W
00H
External Interrupt Flag Register
EIEDGE
A5H
R/W
00H
External Interrupt Flag Edge Register
EIPOLA
A6H
R/W
00H
External Interrupt Flag Polarity Register
EIBOTH
A7H
R/W
00H
External Interrupt Flag Both Edge Enable
Register
CIENAB
B1H
R/W
00H
Comparator Interrupt Flag Enable Register
CIFLAG
ACH
R/W
00H
Comparator Interrupt Flag Register
CIEDGE
ADH
R/W
00H
Comparator Interrupt Flag Edge Register
CIPOLA
AEH
R/W
00H
Comparator Interrupt Flag Polarity Register
CIBOTH
AFH
R/W
00H
Comparator Interrupt Flag Both Edge Enable
Register
CFENAB
D8H
R/W
00H
Comparator Flag Enable Register
CFFLAG
C8H
R/W
00H
Comparator Flag Register
CFEDGE
C0H
R/W
00H
Comparator Flag Edge Register
CFPOLA
B0H
R/W
00H
Comparator Flag Polarity Register
CFBOTH
A0H
R/W
00H
Comparator Flag Both Edge Enable Register
PCI
94H
R/W
00H
Pin Change Interrupt Enable Register
