8. Basic Interval Timer (BIT) MC97F6108A User’s manual
78
8.3 BIT register description
BITCR (Basic Interval Timer Control Register): 8BH
7
6
5
4
3
2
1
0
BITF
BCK2
BCK1
BWDTRC
BCLR
BPD2
BPD1
BPD0
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
Initial value: 45H
BITF
When BIT Interrupt occurs, this bit becomes ‘1’. For clearing bit, write ‘0’ to
this bit or auto clear by INT_ACK signal
0
BIT interrupt no generation
1
BIT interrupt generation
BCK[1:0]
Select BIT clock source
BCK1
BCK0
Description
0
0
fBIT/2048 (default)
0
1
fBIT/256
1
0
fBIT/16
1
1
fBIT/2
BWDTRC
Select BIT Clock Source (fBIT) to WDTRC
0
fSYS
1
fWDTRC
BCLR
If this bit is written to ‘1’, BIT Counter is cleared to ‘0’
After one machine cycle BCLR is cleared automatically.
0
Free Running
1
Clear Counter
BPD[2:0]
Select BIT overflow period
BPD2
BPD1
BPD0
Description
(BIT Clock ≒7.8kHz, default)
0
0
0
0.256ms (BIT Clock * 2)
0
0
1
0.512ms (BIT Clock * 4)
0
1
0
1.024ms (BIT Clock * 8)
0
1
1
2.048ms (BIT Clock * 16)
1
0
0
4.096ms (BIT Clock * 32)
1
0
1
8.192ms (BIT Clock * 64) (default)
1
1
0
16.384ms (BIT Clock * 128)
1
1
1
32.768ms (BIT Clock * 256)
BITR (Basic Interval Timer Register): 8CH
7
6
5
4
3
2
1
0
BIT7
BIT6
BIT5
BIT4
BIT3
BIT2
BIT1
BIT0
R
R
R
R
R
R
R
R
Initial value: 00H
BIT[7:0]
BIT Counter
