10. Timer0/1/2/3 MC97F6108A User’s manual
88
10.5 Register map
Table 15. Register Map
Name
Address
Dir
Default
Description
T0CR
B2
H
R/W
00
H
Timer 0 Mode Control Register
T0CR1
B3
H
R/W
00
H
Timer 0 Mode Control Register 1
T0L
B4
H
R
00
H
Timer 0 Low Register
PWM0DRL
B4
H
R/W
00
H
PWM 0 Duty Register Low
CDR0L
B4
H
R
00
H
Timer 0 Capture Data Register Low
T0H
B5
H
R
00
H
Timer 0 Register High
PWM0DRH
B5
H
R/W
00
H
PWM 0 Duty Register High
CDR0H
B5
H
R
00
H
Timer 0 Capture Data Register High
T0DRL
B6
H
R/W
FF
H
Timer 0 Data Register Low
PWM0PRL
B6
H
R/W
FF
H
PWM 0 Period Register Low
T0DRH
B7
H
R/W
FF
H
Timer 0 Data Register High
PWM0PRH
B7
H
R/W
FF
H
PWM 0 Period Register High
T1CR
BA
H
R/W
00
H
Timer 1 Mode Control Register
T1CR1
BB
H
R/W
00
H
Timer 1 Mode Control Register 1
T1L
BC
H
R
00
H
Timer 1 Register Low
PWM1DRL
BC
H
R/W
00
H
PWM 1 Duty Register Low
CDR1L
BC
H
R
00
H
Timer 1 Capture Data Register Low
T1H
BD
H
R
00
H
Timer 1 Register High
PWM1DRH
BD
H
R/W
00
H
PWM 1 Duty Register High
CDR1H
BD
H
R
00
H
Timer 1 Capture Data Register High
T1DRL
BE
H
R/W
FF
H
Timer 1 Data Register Low
PWM1PRL
BE
H
R/W
FF
H
PWM 1 Period Register Low
T1DRH
BF
H
R/W
FF
H
Timer 1 Data Register High
PWM1PRH
BF
H
R/W
FF
H
PWM 1 Period Register High
T2CR
C2
H
R/W
00
H
Timer 2 Mode Control Register
T2CR1
C3
H
R/W
00
H
Timer 2 Mode Control Register 1
T2L
C4
H
R
00
H
Timer 2 Register Low
PWM2DRL
C4
H
R/W
00
H
PWM 2 Duty Register Low
CDR2L
C4
H
R
00
H
Timer 2 Capture Data Register Low
T2H
C5
H
R
00
H
Timer 2 Register High
PWM2DRH
C5
H
R/W
00
H
PWM 2 Duty Register High
CDR2H
C5
H
R
00
H
Timer 2 Capture Data Register High
T2DRL
C6
H
R/W
FF
H
Timer 2 Data Register Low
