I/O ports
MC97F6108A Us
er’s manual
42
5.3
P1
port
5.3.1
P1 port
description
P1 is
an
8-bit
I/O port.
P1 control registers consist
of P1 data
register (P1), P1
direction
register (P1IO),
debounce
enable
register
(
P15DB),
P1
pull
-up
resisto
r
selection
r
egister
(P1PU),
and
P1
o
pen-drain
selection register (P1OD)
. Refer to
the port func
tion selection r
egisters for the P1 functi
on selection.
5.3.2
Register d
escript
i
on
for
P1
P1 (P1 Data Register):
88H
7
6
5
4
3
2
1
0
P17
P16
P15
P14
P13
P12
P1
1
P10
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
Initial value
:
00H
P1[7:0]
I/O Data
P1IO (P1 Direction R
egister):
91H
7
6
5
4
3
2
1
0
P17IO
P16IO
P15IO
P14IO
P13IO
P12IO
P1
1IO
P10IO
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
Initial value
:
00H
P1IO[7:0]
P1 Data I/O Direction
0
Input
1
Output
P1PU (P1 Pull-u
p Resistor Selection R
egister):
2F08H
7
6
5
4
3
2
1
0
P17PU
P16PU
P15PU
P14PU
P13PU
P12PU
P1
1PU
P10PU
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
Initial value
:
00H
P1PU[7:0]
Configure Pull-up Resistor of P1 Port
0
Disable
1
Enable
P1OD (P1 Open-dra
in Selection Regi
ster):
2F09H
7
6
5
4
3
2
1
0
P17OD
P16OD
P15OD
P14OD
P13OD
P12OD
P1
1OD
P10OD
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
Initial value
:
00H
P1OD[7:0]
Configure Open-drain of P1 Port
0
Push-pull output
1
Open-drain output
41
43
