MC97F6108A Us
er’s manual
12
.
Analog comp
arator and OP
-AMP
133
CA_REG6 (Compar
ator
A
mp Registe
r 6) : 2F36H
7
6
5
4
3
2
1
0
C3NVSL[3]
C3NVSL[2]
C3NVSL[1]
C3NVSL[0]
C2NVSL[3]
C2NVSL[2]
C2NVSL[1]
C2NVSL[0]
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
Initial value: 00
H
C3NVSL[3:0]
Comparator 3 input reference voltage selection
0000
VDD x 20/50
0001
VDD x 21/50
0010
VDD x 22/50
0011
VDD x 23/50
0100
VDD x 24/50
0101
VDD x 25/50
0110
VDD x 26/50
0111
VDD x 27/50
1000
VDD x 28/50
1001
VDD x 29/50
1010
VDD x 30/50
1011
VDD x 32/50
1100
VDD x 34/50
1101
VDD x 36/50
1110
VDD x 38/50
1111
VDD x 40/50
C2NVSL[3:0]
Comparator 2 input reference voltage selection
0000
VDD x 20/50
0001
VDD x 21/50
0010
VDD x 22/50
0011
VDD x 23/50
0100
VDD x 24/50
0101
VDD x 25/50
0110
VDD x 26/50
0111
VDD x 27/50
1000
VDD x 28/50
1001
VDD x 29/50
1010
VDD x 30/50
1011
VDD x 32/50
1100
VDD x 34/50
1101
VDD x 36/50
1110
VDD x 38/50
1111
VDD x 40/50
