MC97F6108A User’s manual 16. Inter Integrated Circuit (I2C)
183
I2CSAR (I2C Slave Address Register): D7H
7
6
5
4
3
2
1
0
SLA7
SLA6
SLA5
SLA4
SLA3
SLA2
SLA1
GCALLEN
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
Initial value: FFH
SLA[7:1]
These bits configure the slave address of this I2C module when I2C
operates in slave mode.
GCALLEN
This bit decides whether I2C allows general call address or not when
I2C operates in slave mode.
0
Ignore general call address
1
Allow general call address
I2CSAR1 (I2C Slave Address Register 1): D6H
7
6
5
4
3
2
1
0
SLA7
SLA6
SLA5
SLA4
SLA3
SLA2
SLA1
GCALLEN
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
Initial value: FFH
SLA[7:1]
These bits configure the slave address of this I2C module when I2C
operates in slave mode.
GCALLEN
This bit decides whether I2C allows general call address or not when
I2C operates in slave mode.
0
Ignore general call address
1
Allow general call address
