MC97F6108A Us
er’s manual
10
.
Timer0/1/2/3
91
TxCR1 (Timer0/1/23 Mode
Control Register 1) :
B3H, BBH, C3H, C
BH
7
6
5
4
3
2
1
0
-
-
TxIN[2]
TxIN[1]
TxIN[0]
ECEN
Tx_PE
POL
-
-
R/W
R/W
R/W
R/W
R/W
R/W
Initial value: 00
H
TxIN[2:0]
Select Event Counter and External Interrupt for Capture mode
TxIN2
TxIN1
TxIN0
description
0
0
0
TxEC0
0
0
1
TxEC1
0
1
0
TxCAP0
0
1
1
TxCAP1
1
0
0
TxCAP2
1
0
1
-
1
1
0
-
1
1
1
-
ECEN
Control Event Counter
0
Event Counter disable
1
Event Counter enable
Tx_PE
Control Timer X Output port
0
Timer X Output disable
1
Timer X Output enable
POL
Configure PWM polarity
0
Negative (Duty Match: Clear)
1
Positive (Duty Match: Set)
TxL (T
im
er0/1/2/3 Registe
r Low
,
Read Case) :
B4H, BCH, C4H, CCH
7
6
5
4
3
2
1
0
TxL7
TxL6
TxL5
TxL4
TxL3
TxL2
TxL1
TxL0
R
R
R
R
R
R
R
R
Initial value: 00
H
TxL[7:0]
TxL Counter Period Low data.
CDR
xL (Capture0/1/2/3 Data Regi
ster Low
, Read C
ase) : B4H, BCH
, C4H, CCH
7
6
5
4
3
2
1
0
CDRxL07
CDRxL06
CDRxL05
CDRxL04
CDRxL03
CDRxL02
CDRxL01
CDRxL00
R
R
R
R
R
R
R
R
Initial value: 00
H
CDRxL[7:0]
Tx Capture Low data.
